Register Portal report

In order for the BPM Portal to be opened and displayed, the corresponding Portal report must be registered.

Instructions - SystemAdministration:

1. Select the Portal 7 report in SystemAdministration under BPM-Portal

2. Click on Register report in the context menu:



3. Make the following settings in the Register report dialog:



   Property	Description
   Name	Name of the BPM portal
   Project ID	Is filled automatically
   Service ID	Is filled automatically
   Label	Is filled automatically
   Default session type	Web API
   Page refresh interval	Is filled automatically
   Enable Single-Sign-On	Enables the single sign-on function on the Portal so that a user's login data is saved and they only have to log in once on their computer.
   Authentication mode	Mode how users can authenticate and log in to the Portal: DATABASE: With the user of the Aeneis database LDAP: LDAP interface LDAP_DATABASE: see above. KERBEROS: Set up Kerberos authentication PROXY: Via a set proxy

4. Click Save

Result:

Once the report has been registered, it can be opened in the browser.

Instructions - ServerAdministration:

1. Navigate to the Databases section in the ServerAdministration

2. In the Actions column of the database, click on Report registration:



3. In the Report registration dialog, click on the Portal report that you want to register:



   Note: Reports that have already been registered are marked with . Reports that have not yet been registered are marked with .

   Note: To remove a registration entry, click on the already registered report in the Report registration dialog.

4. Set the Portal report settings in the Register report dialog

   See also: Step 3 in the instructions - SystemAdministration

   Note: If only one Portal report is stored in a database, the Register report dialog opens directly after you have clicked on Report registration in the Actions column.

5. Click Save

6. In the Report registration dialog, click Report registration on OK
